Build Dimension：832mm×832mm×1500mm（X×Y×Z）
Laser Type：500W×6/8/10
Materials：Titanium Alloy, Superalloy, Aluminum Alloy, Cobalt-Chromium Alloy, Stainless Steel, Die Steel, Copper Alloy, High-Alloy, Refractory Metal, etc.
Integrated Forming of Large-size High-axis Parts
More Efficient, More Open and More Stable
Mass Production Platform for Large Industrial PartsMaterials
Build Dimension
Laser Type
Scanning System
Focusing System
Beam Quality
Beam Diameter
Max Scanning Speed
Powder Bed Thickness
Preheating Temperature
Powder Laying Mechanism
Gas Support
Working Oxygen Content
Building Efficiency
Mainframe Dimension
Installation Dimension
Power Supply
Power Consumption
Equipment Weight
Titanium Alloy, Superalloy, Aluminum Alloy, Cobalt-Chromium Alloy, Stainless Steel, Die Steel, Copper Alloy, High-Alloy, Refractory Metal, etc.
832mm×832mm×1500mm（X×Y×Z）
500W×6/8/10
High-Precision Scanning Galvanometer
F-theta Lens
M2<1.1
70~120μm ( size adjustable )
7m/s
20~100μm
RT+20~200℃
Single/Double Variable Speed
Ar/N2
≤100ppm
150cm3/h；200cm3/h ；250cm3/h
8100mm×5300mm×5400mm（W×D×H）
11100mm×8300mm×6500mm（W×D×H）
AC380V
≤50KW
Around 18000 kg
