High Quality Core Components

Stable and reliable for a long time

Modules Of Design

Easy to assembly and
maintain

The Powder Feeding Structure

Accuracy of powder feeding,
replacement of different metal powders

Multi-scraper Adaptable

Rubber, hairbrush, high-speed steel, ceramic

AdjustableParameters

Built-in parameters
adjustable according to needs

Open-source Parameters

The parameters available for editing and directly use for customer

Real-time monitoring

Real-time recording, output, self-diagnosis

Customer Service

Support the special service for customer

Materials

Build Size

Laser Configuration

Scanning System

Beam Focus System

Beam Quality

Spot Diameter

Max Scanning Speed

Layer Thickness

Powder Spreading

Gas Protection

Oxygen Content

Efficiency

Host Dimension

Installation Dimension

Power Supply

Power Consumption

Equipment Weight

Titanium Alloy, Nickel-Titanium Alloy, Aluminum Alloy, Superalloy, Cobalt-Chromium Alloy, Stainless Steel, Die Steel, Copper Alloy, High-Entropy Alloy, Refractory Metals, etc.

φ170mm×120mm（D×H）

500W×1

High-Precision Scanning Galvanometer

F-theta Lens

M²<1.1

40~80µm

7m/s

20~100μm

Single Variable Speed

Ar/N₂

≤100ppm

25cm³/h

1400mm×800mm×1800mm (W×D×H)

3200mm×2400mm×2380mm (W×D×H)

AC220V

7KW

Around 800kg
